FX3U-14MR / 14MT PLC — Compact 8 Input 6 Output Controller

The FX3U-14MR / 14MT PLC is a Mitsubishi FX3U-compatible programmable logic controller built for compact industrial automation. It delivers 8 digital inputs and 6 digital outputs in a space-saving panel-mount body, with integrated 6 analog inputs and 2 analog outputs (6AD/2DA), a real-time clock (RTC) and MODBUS RTU protocol support. RS485 communication is optional (RS232 is default; choose RS485 when ordering). Program it easily with GX Works2 (also GX Developer). Choose 14MR for relay outputs (5 A per point, AC/DC loads) or 14MT for transistor outputs (1 A per point, high-speed PWM).

6 Key Features

8 Input / 6 Output — space-saving 14-point design for compact control panels.
6AD / 2DA Analog I/O — AD0–AD2 0–10 V, AD3–AD5 0–20 mA; 2DA 0–10 V analog output for precise process control.
Real-Time Clock (RTC) — enables time-stamped logging and scheduled automation tasks.
Optional RS485 Communication — add RS485 for long-distance multi-device networking (RS232 default).
MODBUS Protocol — seamless integration with HMIs, inverters, sensors and SCADA systems.
Program with GX Works2 — standard Mitsubishi programming environment; also supports GX Developer.

FX3U-14MR / 14MT Specifications

Item	FX3U-14MR	FX3U-14MT
Digital Input / Output	8 Input / 6 Output
Output Type	Relay (5 A/pt)	Transistor (1 A/pt)
Input Voltage	24 V / 220 V	24 V DC
Analog Input (6AD)	AD0–AD2 0–10 V, AD3–AD5 0–20 mA
Analog Output (2DA)	2DA 0–10 V
Real-Time Clock (RTC)	Supported
Communication	RS232 default; RS485 optional; MODBUS RTU
Programming Software	GX Works2 / GX Developer
Memory Capacity	8000 steps
Download Speed	38.4 kbps

Applications

Packaging machinery, conveyor systems, textile equipment, food processing, HVAC control and water treatment — anywhere a reliable, FX3U-compatible 8-in/6-out PLC with analog I/O and MODBUS networking is required.

FX3U-14MR/MT PLC Tips :

Optional function

RS485: This PLC is RS232 communication by default,if you need RS485 communication,please choose the right option.

RTC: RTC means real time clock.

Model	FX3U-14MR	FX3U-14MT	FX3U-24MR	FX3U-24MT	FX3U-30MR
Output type	Relay	Transistor	Relay	Transistor	Relay
Download speed	38.4kb	38.4kb	38.4kb	38.4kb	38.4kb
Memory capacity	8000	8000	8000	8000	8000
Input Voltage	24V 220V	24V DC	24V 220V	24V DC	24V 220V
Output Current	5A	1A	5A	1A	5A
Digital Input Point	8	8	14	14	16
Digital Output Point	6	6	10	10	14
Analog Input	AD0~AD2 0-10V AD3~AD5 0-20MA	AD0~AD2 0-10V AD3~AD5 0-20MA	AD0~AD2 0-10V AD3~AD5 0-20MA	AD0~AD2 0-10V AD3~AD5 0-20MA	AD0~AD2 0-10V AD3~AD5 0-20MA
Analog Output	2DA 0-10V	2DA 0-10V	2DA 0-10V	2DA 0-10V	2DA 0-10V
RS485/RTC	Optional	Optional	Optional	Optional	Optional
MODBUS	Optional	Optional	Optional	Optional	Optional
CAN	/	/	/	/	Optional
Software	GX Developer OR GX Works2

Model	FX3U-32MT	FX3U-48MR	FX3U-48MT	FX3U-56MR	FX3U-56MT
Output type	Transistor	Relay	Transistor	Relay	Transistor
Download speed	38.4kb	38.4kb	38.4kb	38.4kb	38.4kb
Memory capacity	8000	8000	8000	8000	8000
Input Voltage	24V DC	24V 220V	24V DC	24V 220V	24V 220V
Output Current	1A	5A	1A	5A	1A
Digital Input Point	16	24	24	32	32
Digital Output Point	16	24	24	24	24
Analog Input	AD0~AD2 0-10V AD3~AD5 0-20MA	AD0~AD2 0-10V AD3~AD5 0-20MA	AD0~AD2 0-10V AD3~AD5 0-20MA	AD0~AD2 0-10V AD3~AD5 0-20MA	AD0~AD2 0-10V AD3~AD5 0-20MA
Analog Output	2DA 0-10V	2DA 0-10V	2DA 0-10V	2DA 0-10V	2DA 0-10V
RS485/RTC	Optional	Optional	Optional	YES	YES
MODBUS	Optional	Optional	Optional	YES	YES
CAN	Optional	Optional	Optional	YES	YES
Software	GX Developer OR GX Works2

Description :

FAQ

Q: What is the difference between FX3U-14MR and 14MT?
A: 14MR uses relay outputs (5 A/point) for AC/DC loads and accepts 24 V or 220 V input; 14MT uses transistor outputs (1 A/point) for high-speed PWM and accepts 24 V DC input.

Q: Which software programs the FX3U-14MR/14MT?
A: It is programmed with Mitsubishi GX Works2 (and GX Developer), the standard FX3U development environment.

Q: Does FX3U-14MR/14MT support RS485 and MODBUS?
A: Yes. MODBUS RTU is supported. RS232 is default; RS485 is optional and can be selected when ordering.

Q: How many analog channels does it have?
A: It integrates 6 analog inputs and 2 analog outputs (6AD/2DA) for temperature, pressure and speed signals.

Explore the full FX3U PLC series for more models.
